FHLR2GCB2G EV Cable

2023-08-18 09:32:42

FHLR2GCB2G silicone high voltage battery cable


Conductor: bare copper


Insulator: Silicone rubber (according to ISO6722)


Outer sheath: High tear-resistant silicone rubber


Weaving: special fiber weaving high temperature coating treatment


Colour: Orange (Ral 2003)


Rated voltage.: AC600/DC900V


Hipot test: AC5000/5 Min.


Rated temperature: -60℃~+180℃


Waterproof grade: IP67


Toxic substance control: ROHS-2011/65/EU


Reference standard: LV216-2:2016, ISO 6722 Class E


Physical and mechanical properties:


Tensile strength: 7.5N/mm2 min.


Insulation elongation at break: ≥200%


Minimum bending radius: 5×OD



application:


This FHLR2GCB2G cable is designed for hybrid and electric vehicle high-voltage wiring systems; also suitable for connecting high-voltage batteries and electric motors.
